Computer automatic cutting machine series Current position:首页>>English>>Products>>Computer automatic cutting machine series

Cutting bed new x series

time:2018-12-28  author:qingdaojinhuaying click: 876 次







一.机器工作环境要求  Machine Work Environment Requirements:

工作温度  0℃—50℃
相对湿度 <90%  无冷凝
周边环境通风,无较大冲击
电       压380V±10%
电源频率50HZ
输入功率<18KW
接电系统集中直接型
气体压力0.55Mpa    160L/min


2. Equipment that the customer needs to prepare before installing the machine

a. Power cord: Specification 5 cores 25 square millimeters; (length according to site location);

b. Air pipe: outer diameter 8MM inner diameter 6MM, pressure 0.5MPa, (length according to site position);

c. Air compressor: power 2 (1.5KW) or more, with filter (oil, water, dust, dry);

d. Forklift: 8 tons long arm. (There must be 20 tons of cranes upstairs, the length of the arm is determined according to the height of the building):

e. Exhaust pipe: PPR outer diameter 110MM, inner diameter 100MM, (with elbow, length according to site position);

f. Voltage regulator: 380V, 30KVA (according to customer voltage fluctuations);

g. Equipment installation, commissioning, etc. are handled by Science and Technology Corporation, and your company provides assistance.


3. Product Features:

1. The discharge system is designed by computer, and it can be automatically and effectively combined with the computer to improve the efficiency of the discharge. The ordinary personnel can master the discharge technique as long as they are familiar with the computer operation.

2. The equipment can achieve zero-pitch cutting, which effectively saves raw materials.

3. Computer controlled automatic cutting, instead of a large number of cutting workers, to achieve mass production.

4. The cutting precision of the cutting piece of the equipment is high, and the lathe can directly sew the sewing without trimming the cutting piece, thereby effectively improving the sewing efficiency of the turning work.

5. The cutting machine control software supports multi-source data format; it can directly receive commonly used clothing design and typesetting software.

6. The equipment adopts automatic sharpening technology, and the grinding time can be designed according to the characteristics of the fabric, which effectively extends the service life of the cutting knife.

7. Consumables are easy to replace and the replacement cost is low.

8. High degree of automation and simple operation.

9. New high-efficiency energy-saving pump design reduces equipment noise and reduces power and energy consumption under the same performance conditions.

10. Intelligent cutting cutter control software effectively improves the cutting quality from top to bottom.

11. Long-life bristle brick cutting window, the blade can penetrate the surface without damage.

12. The conveyor belt can be operated independently or synchronously.

13. Automatically memorize the cutting origin when changing the bed.

14. Automatically adjust the vibration speed of the tool to solve the problem of material hot melt.
